BRAND: MARS EDPAL

Compression Testing Machine (ME CTMF-1000)

Model / Product Code: ME CTMF-1000

Compression Testing Machine used to test compressive strength of bricks

Download PDF

Product Overview

Compression Testing Machine used to test compressive strength of bricks

Capacity : 1000 KN with Hydraulic operation
Digital Display Indicator with load and
capacity display (Microcontroller based)
Leas count : 0.01 KN
Indicator for PEAK, KG, KN and start
Auto cut at Full Load / Peak Load
Max. Clearance between Platens 390 mm
Max. Clearance between Side Platens 390 mm
Platen Size : 140 mm2
Piston Diameter : 78.7 mm
Hand Wheel control for Hydraulic Pressure
For more details please refer datasheet.



Technical Specifications

Product Name Compression Testing Machine
Model / Product Code ME CTMF-1000
Brand MARS EDPAL
Category Scientific, Analytical and Laboratory Eqp.
Sub-Category Mechanical & Civil Lab Equipments
Technical Details

Capacity : 1000 KN with Hydraulic operation
Digital Display Indicator with load and
capacity display (Microcontroller based)
Leas count : 0.01 KN
Indicator for PEAK, KG, KN and start
Auto cut at Full Load / Peak Load
Max. Clearance between Platens 390 mm
Max. Clearance between Side Platens 390 mm
Platen Size : 140 mm2
Piston Diameter : 78.7 mm
Hand Wheel control for Hydraulic Pressure
For more details please refer datasheet.
