BRAND: TECHNICAL SYSTEMS

Display Unit (CM7291)

Model / Product Code: CM7291

Multi-functional Receiving and Display Unit to Use Right on the Field or Output to Advanced Recorder or Logger

Download PDF

Product Overview

Multi-functional Receiving and Display Unit to Use Right on the Field or Output to Advanced Recorder or Logger

Multi-functional Receiving and Display Unit to Use
Output to Advanced Recorder or Logger
Measurement parameters:DC,AC,DC+AC,Hz
Crest factor:3at 5000 count
Output method:WAVE, RMS, PEAK, FREQ
Input connectors:HIOKI PL 14
PEAK sensing duration:2 ms or greater
Other functions    Auto range,Zero adjustment at power-up,
Analysis display, Filter, Output amplification,
For more details refer datasheet.

Technical Specifications

Product Name Display Unit
Model / Product Code CM7291
Category Testing And Measuring Instruments
Sub-Category Clamp Meter
Technical Details

Multi-functional Receiving and Display Unit to Use
Output to Advanced Recorder or Logger
Measurement parameters:DC,AC,DC+AC,Hz
Crest factor:3at 5000 count
Output method:WAVE, RMS, PEAK, FREQ
Input connectors:HIOKI PL 14
PEAK sensing duration:2 ms or greater
Other functions    Auto range,Zero adjustment at power-up,
Analysis display, Filter, Output amplification,
For more details refer datasheet.
