BRAND: MECO

Handheld Thermal Imaging Camera (TIC 300)

Model / Product Code: TIC 300

TIC300 is a Thermal Imaging Camera which combines the functions of surface temperature measurement and real-time thermal imaging.

Download PDF

Product Overview

TIC300 is a Thermal Imaging Camera which combines the functions of surface temperature measurement and real-time thermal imaging.

TIC300 is a Thermal Imaging Camera which combines the
functions of surface temperature measurement and real-time
thermal imaging.
Display : 2.4" Color Display
Resolution : 60 X 60
Total Pixels : 3600
FOV / Shortest Focal Length : 20° x 20° / 0.5m
Thermal Sensitivity : 0.3°C
Measuring Mode : Infrared Focal Plane Measuring Termperature
Temperature Range : -20°C ~ 300°C / -4°F ~ 572°F
Measuring Accuracy : ±2% digital / ±2°C
Wavelength Range : 8 ~ 14µm
For more details please refer datasheet.

Technical Specifications

Product Name Handheld Thermal Imaging Camera
Model / Product Code TIC 300
Brand MECO
Category Testing And Measuring Instruments
Sub-Category Infrared Thermometer
Technical Details

TIC300 is a Thermal Imaging Camera which combines the
functions of surface temperature measurement and real-time
thermal imaging.
Display : 2.4" Color Display
Resolution : 60 X 60
Total Pixels : 3600
FOV / Shortest Focal Length : 20° x 20° / 0.5m
Thermal Sensitivity : 0.3°C
Measuring Mode : Infrared Focal Plane Measuring Termperature
Temperature Range : -20°C ~ 300°C / -4°F ~ 572°F
Measuring Accuracy : ±2% digital / ±2°C
Wavelength Range : 8 ~ 14µm
For more details please refer datasheet.
