BRAND: MARS EDPAL

Impact Of Jet Of Vanes Apparatus (GN 7208)

Model / Product Code: GN 7208

To varify the momentum equation by impact  of jet on different shapes

Download PDF

Product Overview

To varify the momentum equation by impact  of jet on different shapes

To varify the momentum equation by impact
of jet on different shapes
Target (3 Nos.) Made of Acrylic:
a) Hemispherical cup 100mm dia
b) Flat plate 50mm dia
c) Inclined plate 45 degree
Nozzle (SS): 10mm dia, 75mm long
Weighing Scale: To measure jet force
Measuring Tank: 300mm x 300mm x 300mm (LxBxH)
Sump Tank: 600mm x 300mm x 300mm (LxBxH)
Tanks made of SS sheet
Piping & Fittings: Gl material used
For more details please refer datasheet.

Technical Specifications

Product Name Impact Of Jet Of Vanes Apparatus
Model / Product Code GN 7208
Brand MARS EDPAL
Category Scientific, Analytical and Laboratory Eqp.
Sub-Category Mechanical & Civil Lab Equipments
Technical Details

To varify the momentum equation by impact
of jet on different shapes
Target (3 Nos.) Made of Acrylic:
a) Hemispherical cup 100mm dia
b) Flat plate 50mm dia
c) Inclined plate 45 degree
Nozzle (SS): 10mm dia, 75mm long
Weighing Scale: To measure jet force
Measuring Tank: 300mm x 300mm x 300mm (LxBxH)
Sump Tank: 600mm x 300mm x 300mm (LxBxH)
Tanks made of SS sheet
Piping & Fittings: Gl material used
For more details please refer datasheet.

Need Help With This Product?

Talk To Our Technical Experts

Contact Us
