Loss Due To Friction In Pipe Lines (GN 7230)

Model / Product Code: GN 7230

To determine the friction factor (Coefficient of  discharge)for the 4 different material of pipes.

Download PDF

Product Overview

To determine the friction factor (Coefficient of  discharge)for the 4 different material of pipes.

To determine the friction factor (Coefficient of
discharge)for the 4 different material of pipes.
Pipe Line: Provided 4 nos. of different material
1300mm long ID 15mm (Aluminum, Copper, Brass, GI)
Pressure Measurement: 'U' Tube differential manometer
Measuring Tank: 300mm x 300mm x 300mm (LxBxH)
Sump Tank: 600mm x 300mm x 300mm (LxBxH)
Tanks made of SS sheet
Piping & Fittings: Gl material used
Tee Handle Valve: 8nos.
Pump: 0.5HP Single phase, 220VAC±10%
For more details please refer datasheet.

Technical Specifications

Product Name Loss Due To Friction In Pipe Lines
Model / Product Code GN 7230
Brand MARS EDPAL
Category Scientific, Analytical and Laboratory Eqp.
Sub-Category Mechanical & Civil Lab Equipments
Technical Details

To determine the friction factor (Coefficient of
discharge)for the 4 different material of pipes.
Pipe Line: Provided 4 nos. of different material
1300mm long ID 15mm (Aluminum, Copper, Brass, GI)
Pressure Measurement: 'U' Tube differential manometer
Measuring Tank: 300mm x 300mm x 300mm (LxBxH)
Sump Tank: 600mm x 300mm x 300mm (LxBxH)
Tanks made of SS sheet
Piping & Fittings: Gl material used
Tee Handle Valve: 8nos.
Pump: 0.5HP Single phase, 220VAC±10%
For more details please refer datasheet.
