Morgan Chopper (ME 808)
To Study the Working of Morgan Chopper & Observe various waveforms on CRO.
Product Overview
To Study the Working of Morgan Chopper & Observe various waveforms on CRO.
To Study the Working of Morgan Chopper
& Observe various waveforms on CRO.
In built power supply of range +15V DC / 200mA.
One number of Digital Panel Meter for voltage
measurement of range 0-20V.
One number of Digital Panel Meter for current
measurement of range 0-2A.
Selector Switch for selecting capacitance of
different values i.e. 10mF, 20mF and 30mF.
For more details please refer datasheet.
Technical Specifications
To Study the Working of Morgan Chopper
& Observe various waveforms on CRO.
In built power supply of range +15V DC / 200mA.
One number of Digital Panel Meter for voltage
measurement of range 0-20V.
One number of Digital Panel Meter for current
measurement of range 0-2A.
Selector Switch for selecting capacitance of
different values i.e. 10mF, 20mF and 30mF.
For more details please refer datasheet.
