Push-Pull Amplifier (ME 620)

Model / Product Code: ME 620

Push-Pull Amplifier Apparatus has been designed to study the Output Gain, Output Power and Frequency Response of a Push Pull Amplifier

Download PDF

Product Overview

Push-Pull Amplifier Apparatus has been designed to study the Output Gain, Output Power and Frequency Response of a Push Pull Amplifier

Push-Pull Amplifier Apparatus has been designed
to study the Output Gain, Output Power and Frequency
Response of a Push Pull Amplifier.
Transistor : CL-100 (NPN) 3 Nos
Potentiometer : 1 Nos.
Biasing Resistances
Capacitors
SPDTSwitch
Power requirement : 230 VAC 10%, 50Hz
For more details please refer datasheet.

Technical Specifications

Product Name Push-Pull Amplifier
Model / Product Code ME 620
Brand MARS EDPAL
Category Scientific, Analytical and Laboratory Eqp.
Sub-Category Electronics Lab Training Modules
Technical Details

Push-Pull Amplifier Apparatus has been designed
to study the Output Gain, Output Power and Frequency
Response of a Push Pull Amplifier.
Transistor : CL-100 (NPN) 3 Nos
Potentiometer : 1 Nos.
Biasing Resistances
Capacitors
SPDTSwitch
Power requirement : 230 VAC 10%, 50Hz
For more details please refer datasheet.
