BRAND: METREX

Salt Bath Furnace (MSB-1000)

Model / Product Code: MSB-1000

Construction: Cylindrical in shape, having top opening, with manual cover closing. Heating element are placed on the circumference and over the height. Insulation by ceramic fiber blanket with outer mild steel casing.

Download PDF

Product Overview

Construction: Cylindrical in shape, having top opening, with manual cover closing. Heating element are placed on the circumference and over the height. Insulation by ceramic fiber blanket with outer mild steel casing.

Salt bath furnace for quenching up to 800°C
Bath Volume: Dia = 70cm, Depth = 70cm
Material of Crucible: SS 310, 8mm Thickness
Heating Element: Kanthal A1
Temp. Range: 150°C to 800°C
Temp. Control : + 1°C
Operation: 6 to 12 HRS
Temp. Control: PID Temp. Control with
contactor / Relay etc.
Construction: Cylindrical in shape, having top
opening, with manual cover closing.
For more details please refer datasheet.

Technical Specifications

Product Name Salt Bath Furnace
Model / Product Code MSB-1000
Brand METREX
Category Scientific, Analytical and Laboratory Eqp.
Sub-Category Furnaces
Technical Details

Salt bath furnace for quenching up to 800°C
Bath Volume: Dia = 70cm, Depth = 70cm
Material of Crucible: SS 310, 8mm Thickness
Heating Element: Kanthal A1
Temp. Range: 150°C to 800°C
Temp. Control : + 1°C
Operation: 6 to 12 HRS
Temp. Control: PID Temp. Control with
contactor / Relay etc.
Construction: Cylindrical in shape, having top
opening, with manual cover closing.
For more details please refer datasheet.

Need Help With This Product?

Talk To Our Technical Experts

Contact Us

Related Products

Brand: METREX

Tilting Furnace (MTF-10)

Maximum Temperature : 1100°C Crucible Silicon Carbide Pot Capacity 10kg. (Aluminium) Thermocouple : K Type Temp. Controller : PID Digital Temperature Controller Power Relay : Contactor Control Panel : Separate Tilting : Manual Fabrication : Heavy Angle Ir

Download PDF
Brand: METREX

Rectangular Furnace (MRF-100)

Inner muffle size: 24inch wide, 30 inch depth and 24inch high. Temperature of the furnace is controlled by programmable microprocessor based PID controller, (master-slave set up) with soft touch key pad and dual display of process and set temperature. Tem

Download PDF
Brand: METREX

Vacuum Furnace (MVF-1000)

Vacuum Pump and Valve: Pumping rate: 200 It./min Vacuum Double stage pump 10-2 torr by mechanical pump (on pump head) KF-25 adapter and stainless steel pipe are connected between pump and tube flange with precision ball valve

Download PDF
Brand: METREX

MUFFLE FURNACE - 1200°C / 950°C (MF-9M / MF-12M)
