BRAND: MARS EDPAL

Metacentric Height Apparatus (GN 7247)

Model / Product Code: GN 7247

To determination of the metacentric height  and position of the metacentric height with  angle of heel of ship model

Download PDF

Product Overview

To determination of the metacentric height  and position of the metacentric height with  angle of heel of ship model

To determination of the metacentric height
and position of the metacentric height with
angle of heel of ship model.
Ship Model: Size 200 x 200mm with a horizontal
guide bar for aliding weight and removable strips,
graduated arc with pointer with moveable hanger
and set of weights
Pendulum and graduated arc for accurate measurement
of tilt angle
Water Tank: 600mm x 600mm x 300mm (LxBxH)
Tanks made of SS sheet
For more details please refer datasheet.

Technical Specifications

Product Name Metacentric Height Apparatus
Model / Product Code GN 7247
Brand MARS EDPAL
Category Scientific, Analytical and Laboratory Eqp.
Sub-Category Mechanical & Civil Lab Equipments
Technical Details

To determination of the metacentric height
and position of the metacentric height with
angle of heel of ship model.
Ship Model: Size 200 x 200mm with a horizontal
guide bar for aliding weight and removable strips,
graduated arc with pointer with moveable hanger
and set of weights
Pendulum and graduated arc for accurate measurement
of tilt angle
Water Tank: 600mm x 600mm x 300mm (LxBxH)
Tanks made of SS sheet
For more details please refer datasheet.
