Nozzlemeter Test Rig (GN 7228)
To determine co-efficient of discharge of nozzlemeter
Product Overview
To determine co-efficient of discharge of nozzlemeter
To determine co-efficient of discharge of nozzlemeter
Nozzlemeter: 265mm x 75mm x 75mm (LxBxH) made of clear
acrylic conduit
Diameter of Conduit: 25mm ID, centre point 13mm
Pressure Measurement: 'U' Tube differential manometer
Measuring Tank: 300mm x 300mm x 300mm (LxBxH)
Sump Tank: 600mm x 300mm x 300mm (LxBxH)
Tanks made of SS sheet
Pizometer tube with scale provided on all tanks for
water level measurement
For more details please refer datasheet.
Technical Specifications
To determine co-efficient of discharge of nozzlemeter
Nozzlemeter: 265mm x 75mm x 75mm (LxBxH) made of clear
acrylic conduit
Diameter of Conduit: 25mm ID, centre point 13mm
Pressure Measurement: 'U' Tube differential manometer
Measuring Tank: 300mm x 300mm x 300mm (LxBxH)
Sump Tank: 600mm x 300mm x 300mm (LxBxH)
Tanks made of SS sheet
Pizometer tube with scale provided on all tanks for
water level measurement
For more details please refer datasheet.
