Single Phase Cyclometer (ME 804)

Model / Product Code: ME 804

Designed to convert line frequency to 1/2,1/3 & 1/4 of its value & observe the wave form on CRO Power supply +9volt DC for reference.

Download PDF

Product Overview

Designed to convert line frequency to 1/2,1/3 & 1/4 of its value & observe the wave form on CRO Power supply +9volt DC for reference.

Designed to convert line frequency to 1/2,1/3
& 1/4 of its value & observe the wave form on CRO
Power supply +9volt DC for reference.
In built IC based DC regulated power supply +5VDC.
Three separate supplies V1, V2 and V3 of +5Volt
DC each for opto isolators (MCT2E).
Built in clock generator.
Frequency selection switch for selecting frequencies
of 25Hz, 16.66 & 12.5Hz.
For more details please refer datasheet.

Technical Specifications

Product Name Single Phase Cyclometer
Model / Product Code ME 804
Brand MARS EDPAL
Category Scientific, Analytical and Laboratory Eqp.
Sub-Category Power Electronics Lab Training Module
Technical Details

Designed to convert line frequency to 1/2,1/3
& 1/4 of its value & observe the wave form on CRO
Power supply +9volt DC for reference.
In built IC based DC regulated power supply +5VDC.
Three separate supplies V1, V2 and V3 of +5Volt
DC each for opto isolators (MCT2E).
Built in clock generator.
Frequency selection switch for selecting frequencies
of 25Hz, 16.66 & 12.5Hz.
For more details please refer datasheet.
